Details Q-BOL portable light
The Q-Portable lighting products are the smallest in the market. This reduces obstructions next to the runway or at barricades. The Q-BOL is available in several configuration from single colour portable light to multi-purpose portable light including IR.
Features
- Cost effective
- LED technology reduces maintenance time and costs
- Robust design for use in harsh environments
- Available configurations as per different compliance requirements
- No cables required for quick and low cost installation
- Optional IR
Q-BOL is the smaller brother of Q-SPAL. This portable light operates autonomously up to 100 hours. Just like Q-SPAL it can be operated manually or remotely. Portable lighting Q-BOL is IP 67 and made of high quality materials. Portable Q-BOL lighting and portable Q-SPAL solar lamps come in various configurations to meet all customer requirements. Our product certainly meets your requirements.
Order code Q20PT00 – Q-BOL
Q20PT00–11R1 Q-BOL single colour
Q20PT00–12R1 Q-BOL multi-colour
Q20PT00–13R1 Q-BOL multicolour + IR
Additional Information
| Article Number: | Q20PT00 |
| Manufacturer: | Q-Aviation B.V. |
| HS-Code: | 94054031 |
| Warranty: | 2 years |
Product Specifications
| Application: | Runway Barricade light, Runway Threshold Light, Runway Edge light, Runway approach light Runway Apron light Taxiway lighting |
| Light Colour: | Red 630 nm, Green 530 nm, White 5.700K, Yellow 590 nm, Blue 473 nm and IR 850 n |
| Light Source: | LED |
| Light Intensity: | see figure datasheet |
| Vertical Beam Profile: | see figure datasheet |
| Colour chromaticity: | see figure datasheet |
| Enclosure: | GRP & Anodized aluminium |
| Mounting: | 4x magnet, Optional mounting plat |
| Operating voltage: | 12Vdc |
| Tested Ambient Temp: | -25° to +65° C |
| Life expectancy: | 75.000+ hours IP |
| Ingress Protection: | IP 67 |
| In Compliance With: | ICAO Annex 14 FAA |
| Battery: | Rechargeable / 12V, 12AH A-Quality |
| Energy Storage: | On-board battery status |
| Construction: | UV-resistant polycarbonate lens |
Size and Dimension
| Weight: | 9,35 kg |
| Dimension: | 184 x 184 x 278 mm |
| Dimension Packaging: | 200x200x300 mm (LxWxH) |
