Q-PAPI Lighting unit (4 units)

Certificates

ICAO

Technical details

IP65 CE ROHS

Datasheet, Manuals and Drawings

Details Precision approach path indicator

The precision approach path indicator system consists of a single lighting unit to provide a visual indication of the correct approaching path of an airplane. In compliance with ICAO requirements, the Q-PAPI System is located adjacent to the nominal runway and usually comes with 4 units.

The intensity of the Q-PAPI can be manually switched during night time or daytime to the following:
5% (FAA),
10% (ICAO),
20% (FAA),
30% (ICAO)
100% for daylight intensity.

Order code Q73PT01- Q-PAPI Rigid Safe Area

Q73PT01–11 Input power: 100-240 Vac
Q73PT01–12 Input power: 24 Vdc
Q73PT01–13 Input power: 2.8 – 6.6 A

Additional Information

Article Number: Q73PT01
Manufacturer: Q-Aviation B.V.
HS-Code: 94054031
Warranty: 2 years

Product Specifications

Application: Airport/ Portable
Light Colour: White 5.700K / Red 630 nm
Light Source: LED, Steady burning
Light Intensity: 30.000 cd white & 15.000 cd red (ICAO)
Colour chromaticity: as per ICAO, White 5.700K, red 630nm
Photometry: According ICAO Annex 14 Volume II
Enclosure: Aluminium, Powder coated
Mounting: Rigid
Tested Ambient Temp: -25° to +65° C
Suitable For: Safe Area
Life expectancy: 100.000+ hours
Ingress Protection: IP 65
In Compliance With: ICAO Annex 14 FAA L-880/ 881 & E-3007

Size and Dimension

Weight: 30 kg
Dimension: 825 x 489 x 617 mm (L x W x H)
Dimension Packaging: 900 x 550 x 700 mm (L x W x H)
