Q-FULL FLUSH PERIMETER LIGHT (TLOF)

Certificates

CAP437

Technical details

IP67 CE ROHS

Datasheet, Manuals and Drawings

Details

The Q-Full Flush Perimeter Light (TLOF) with IR option is 60 cd, 200 mW/sr perimeter light for all Helipad, Heliport and Airport facilities. The Q-Full Flush Perimeter Light (TLOF) is available in several configurations such as 100-240 VAC and 24 VDC and used in cold areas where snow shovels are being used to clean the area.



Order code Q10FF03 – Q-Full Flush Perimeter Light

11 Input power: 100-240 VAC
12 Input power: 24 VDC

NA Excluding IR
IR   Including IR

Additional Information

Article Number: Q10FF03
Manufacturer: Q-Aviation B.V.
HS-Code: 94054039
Warranty: 2 years

Product Specifications

Application: Helipad
Suitable For: Safe Area
Zone: Safe Area
Light Color: 1) Green, 530nm + Infrared 850nm
Light Source: LED, steady burning
Light Intensity: 60 cd green + 200mW/sr infrared
IR Light Intensity: 200 mW/sr
Dimming: 0-10 VDC (PWM)
Enclosure: Aluminium, Powder coated RAL5015/ Polyacrylate glass
Mounting: Flushmount, 2x M6
External earthing: up to 4mm2 / AWG 12
Input Voltage: From Controller
Cable: H07RN-F 3x2,5mm²
Tested Ambient Temp: -25°C to + 60°C
Incompliance with: ICAO annex 14, CAP437
Cable glands included: 1 x M20x1.5
Cable outer dimension : 12 - 16mm
Consumption: 8 Watt Green
16 Watt Green+IR
Life expectancy: 100.000+ hours
Cable bottom entry: 1 x M20x1.5
Cable stops included: 1 x M20x1.5
Ingress Protection: IP67
Cable glands: 1 x M20x1.5
Cable size: 12 - 16mm
Ambient temp: -25°C to + 60°C

Size and Dimension

Weight: 2.2 Kg
Dimension: 203x203x109mm (LxWxH)
Dimension Packaging: 250x250x250mm (LxWxH)
